The CS-1224G is ideal for micro-segmenting large networks into smaller networks, connecting subnets for improved performance, and enabling the bandwidth demanded for multimedia and imaging applications. Moreover, the 10/100/1000Mbps Auto-Sensing ability provides an easy way to migrate Gigabit network without pain. By integrating both data transmitting cable and power cord, the hassle of constructing your network can be eliminated, allowing you to easily connect your wired LAN network. This switch defines new green power saving idea in all Ports. Using the 802.3az Energy Efficient Ethernet standard, the network will automatically decrease the power usage when traffic is low with no setup required. It can solve the limitation of the network local LAN and offer the system relocation easily Plug & play and all kinds of network protocols compilation make the installation of the device both simple and quick. With auto-MDI/MDIX support, there is no need for any Crossover cables when you connect the device to a computer, or even another switch. In addition, the auto-negotiation function auto-senses and adjusts the  connected devices whether they are running at 10Mbps, 100Mbps, or 1000Mbps.

The CS-1224G also supports Low Power Idle Mode. When Low Power Idle Mode is enabled, systems on both sides of the link can disable portions of functionality and save power during periods of low link utilization, reducing power consumption. With its nonblocking architecture, the Green Ethernet switch receives and forwards the traffic seamlessly. Duplex mode also doubles the bandwidth by enabling two-way communication. Totaling up to 52Gbps of switching capacity to a shared total 10/100/1000 Mbps network.

Highlight Features

• Complying with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-X , IEEE 802.3az specifications.
• 24 Port 10/100/1000Mbps TX Auto-Negotiation Ethernet Switch.
• Supports 2 Gigabit SFP Fiber uplink ports for IEEE 802.3z 1000Base-SX/LX.
• Supports Energy-Efficient Ethernet (EEE), IEEE 802.3az standard.
• Supports IEEE 802.1p CoS Class of service.
• Supports VLAN packet pass-through function.
• Supports Green Ethernet features, Link-On and Cable Length Power Saving, Link-Down Power Saving, Power saving mode support to automatic cable detection.
• Supports auto-detection for SFP ports / mini-GBIC module insertion.
• Half/Full-duplex capability on each TX port Autolearning networking configurations.
• Provides 10K Jumbo frames to improve network utilization of a large file transfers.
• Supports Store & Forward architecture and performs forwarding and filtering.
• IEEE802.3x flow control for Full-duplex, Back Pressure function for Half-duplex operation.
• Non-blocking & Non-head-of-line blocking fullwire speed forwarding.
• Supports TP interface Auto MDIX function for auto TX/RX swap.
• Automatic Source MAC Address Learning and Aging.
• Supports up to 8K MAC addresses and Up to 4 .1Mb buffer memory.
